NOx NH3 CLD 분석장치
ECO Physics
 |
|
 |
 |
|
|
| [nCLD 6x Series] |
단일 NOx NH3 품목 전문 기업인 ECO Physics AG(Swiss)의 분석장치는 장치의 구성과 신뢰성에서전세계 사용자들의 찬사를 받고 있는 가장 신뢰성있는 현 시대의 최고의 NO NO2 NOx, NH3, NOamine 분석 장치입니다
https://www.ecophysics.com/catalog/ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
 |
|
| Measuring ranges | four freely selectable ranges from 5 ppm –5’000 ppm | | Min. detectable concentration* | 0.5 ppm | | Noise at zero point (1σ)* | 0.25 ppm | | Lag time | <1 sec | | Rise time (0-90%) | <3 sec | | Temperature range | 10-40 °C | | Humidity tolerance | 5-95% rel. h (non-condensing, ambient air and sample gas) | | Dry air use for O3 generator | internally generated (no external supply gas required) | | Sample flow rate | 0.3 l/min | | Input pressure | ambient externally stabilized within ±3 mbar | | Power required | 280 VA, 250 VA external membrane pump | | Supply voltage | 100–230 V/50–60 Hz | | Interface | USB(2x), HDMI, Bluetooth, RS232 (w/o 9 pin connector), LAN, WLAN | | Dimensions | height: 133 mm (5¼”) width: 430 mm (17”) depth: 450 mm (20”) | | Weight | 16 kg (35 lb) without pump | | Delivery includes | nCLD 62 analyzer, power cable, USB-LAN adapter, manual | | Standard | nCLD 62: NO/NOX analyzer with internal metal converter | | Options | · steel converter orologi replica italia · rack mount slides · inlet filter · USB-RS232 9pin connector · FTDI-RS232-USB cable · 24 V operation incl. DC vacuum pump · analog output (external box): 4-20 mA into 500 Ω max.; 0-10 V |
replica horloges |
|
|
 |
